M32 Lower Mainshaft 18T and Components 3.83 Ratio RPO:MZ0 Astra H VXR

Contact us for availability M32 Lower Mainshaft Shaft and Associated Components
M32 Lower Mainshaft Shaft and Associated Components
  • Views: 20157
  • Product Code: 55491766
  • Availability: Contact us for availability
  • £0.00
  • Ex Tax: £0.00

Available Options

-+

Lower Mainshaft 18 Teeth 3.83 Ratio and Associated Components for M32 Gearbox RPO* MZ0 (Astra H VXR 3.83 Final Drive)

Components Available are:
Lower Mainshaft 18T (Ref: 1 - was 55587838), Needle Bearing 1st (Ref: 5), Thrust Bearing 1st (Ref: 4), 1st Gear 42T (Ref: 6), Synchro Ring 1st and 2nd (Ref: 7) - Qty:2, Synchro Assembly 1st and 2nd (Ref: 8/9), Needle Bearing 2nd (Ref: 12), Needle Bearing 5th (Ref: 12), 2nd Gear 41T (Ref: 11), Retaining Ring 2nd (Ref: 13), Thrust Washer 2nd (Ref: 14), 5th Gear 35T (Ref: 15), Synchro Ring 5th (Ref: 16), Synchro Assembly 5th and 6th Gear (Ref: 17/18), Synchro Ring 6th (Ref: 19), Retaining Ring 32x2mm (Ref: 20), Needle Bearing 6th Gear (Ref: 21), 6th Gear 29T (Ref: 22)
Note: Bearings (Ref: 2 & 23) - Part of Gearbox Bearing Kit

Order required parts via the drop down options listing.

*RPO (Regular Production Option) refers to General Motors Vehicle Configuration Options.

NOTE: Schematic diagram is for reference only. Parts are as listed. Always check suitability prior to ordering.
